All-in-One Battery Systems CE

All-in-One Battery Systems (MS-SPS1600-A-G1)

Balcony solar storage system with a 512V LiFePO₄ pack, 2048Wh per module and parallel expansion to 240kWh — plug-and-play storage for residential and light commercial roofs.

All-in-One Battery Systems (MS-SPS1600-A-G1)

Technical Specifications

Key Features

  • Battery Type: LiFePO₄
  • DoD: 90%
  • Max Charge: 60A DC Input
  • MPPT Range: 18-60V
  • Efficiency: 98% max
  • Parallel Expandable: Yes
  • Max Parallel Capacity: 240kWh
  • Rating: IP65
  • Communication: WiFi

Specifications

  • 512V (16S) LiFePO₄ battery
  • 2048Wh capacity per module
  • 6000 cycles @25°C

Specification Table

Output

Battery type
LiFePO₄, 512 V (16S)
Capacity per module
2048 Wh
Max. parallel capacity
240 kWh

Performance

Depth of discharge
90%
Cycle life
6,000 cycles @ 25°C
Max. efficiency
98%

Input

Max. charge current
60 A DC
MPPT range
18-60 V

Mechanical

IP rating
IP65

Communication

Communication
WiFi

Model Matrix

Every model number in this line, with rated power, outputs and electrical ratings. Request the datasheet for full parameter curves.

ModelRated powerOutputsMax. currentQuote
MS-SPS1600-A-G12048 Wh160 A DC charge Quote

1 model in this line · link any row with #model-<number>

Applications

Residential Solar
Commercial Storage
Microgrids
Custom / OEM Scenarios

Frequently Asked Questions

How much energy does one module store, and can it be expanded?

Each module stores 2048 Wh in a 512 V (16S) LiFePO₄ pack, and modules can be paralleled up to a total of 240 kWh for residential and light commercial storage.

What is the battery lifespan and usable depth of discharge?

6,000 cycles at 25°C, 90% depth of discharge, and up to 98% efficiency.

How does it connect to solar, and how is it monitored?

MPPT range is 18-60 V with a maximum charge current of 60 A DC. Communication is over WiFi, and the enclosure is IP65.

What certifications does it have?

CE certified. Typical applications are residential solar, commercial storage and microgrids.
