Split-Type DC Fast Charging Cabinet
FEVD split-system DC fast charging platform: a 240-720kW power cabinet feeding up to ten charging terminals. Modular 30-40kW power modules, OCPP 1.6J, and NEVI-ready configuration for gas stations, fleet depots and highway corridors.
Technical Specifications
Key Features
- High efficiency ≥95%
- Smart HMI with one-touch operation
- Power cabinet + terminal split architecture
- Input: AC 260-530 V, 45-65 Hz
- Power factor ≥0.99 (≥50% load), THD <5%
- Ethernet / 4G connectivity
- IP55 protection, -25°C to +50°C operation
Specifications
- 240-720 kW power cabinet ratings
- Modular 30 kW / 40 kW power modules
- Wide output voltage range: 200-1000 Vdc
Specification Table
Output
- Cabinet ratings
- 240 / 360 / 480 / 640 / 720 kW
- Output voltage
- 200-1000 Vdc
- Max. current per connector
- 200 Adc
- Outputs per cabinet
- 6 / 9 / 10 depending on rating
- Power module
- 30 kW / 40 kW hot-swappable
Input
- Input voltage
- 260-530 Vac
- Input frequency
- 45-65 Hz
Performance
- Efficiency
- ≥95% at 50-100% load
- Power factor
- ≥0.99 at ≥50% load
- THD
- <5%
- Metering accuracy
- Class 1
Protection
- Protection
- Over-voltage, over-current, short-circuit, residual current, insulation monitoring
Mechanical
- IP rating
- IP55
Environment
- Operating temperature
- -25°C to +50°C
Communication
- Protocol
- OCPP 1.6J
- Connectivity
- Ethernet / 4G
- Total output current for the 360 kW and 480 kW cabinets is being re-confirmed with our engineering team — request the datasheet for the exact figure before sizing cable runs.
- The same FEVD platform also ships as an all-in-one cabinet from 30 kW to 160 kW; those models are listed separately in the table below.
Model Matrix
Every model number in this line, with rated power, outputs and electrical ratings. Request the datasheet for full parameter curves.
Split system
| Model | Role | Rated power | Outputs | Max. current | Output voltage | Input voltage | Dimensions (W×D×H) | Connectivity | Quote |
|---|---|---|---|---|---|---|---|---|---|
| FEVD21360* | Power cabinet | 360 kW | 6 | 200 Adc per connector | 200-1000 Vdc | 260-530 Vac | 1600 x 800 x 1950 mm | Ethernet / 4G / WiFi / Bluetooth | Quote |
| FEVD21480* | Power cabinet | 480 kW | 6 | 200 Adc per connector | 200-1000 Vdc | 260-530 Vac | 1600 x 800 x 1950 mm | Ethernet / 4G / WiFi / Bluetooth | Quote |
| FEVD21250* | Charging terminal | 250 kW | 2 | 200 Adc | 200-1000 Vdc | TBC | 1600 x 800 x 1950 mm | Ethernet / 4G / WiFi / Bluetooth | Quote |
All-in-one
| Model | Role | Rated power | Outputs | Max. current | Output voltage | Input voltage | Dimensions (W×D×H) | Connectivity | Quote |
|---|---|---|---|---|---|---|---|---|---|
| FEVD12030 | Floor-standing charger | 30 kW | 1 | 100 Adc | 200-1000 Vdc | 260-530 Vac | 700 x 300 x 1700 mm | Ethernet / 4G / WiFi / Bluetooth | Quote |
| FEVD21060 | Floor-standing charger | 60 kW | 2 | 200 Adc | 200-1000 Vdc | 260-530 Vac | 700 x 501 x 1730 mm | Ethernet / 4G / WiFi / Bluetooth | Quote |
| FEVD21080 | Floor-standing charger | 80 kW | 2 | 200 Adc | 200-1000 Vdc | 260-530 Vac | 700 x 501 x 1730 mm | Ethernet / 4G / WiFi / Bluetooth | Quote |
| FEVD21120 | Floor-standing charger | 120 kW | 2 | 200 Adc | 200-1000 Vdc | 260-530 Vac | 700 x 501 x 1730 mm | Ethernet / 4G / WiFi / Bluetooth | Quote |
| FEVD21160 | Floor-standing charger | 160 kW | 2 | 200 Adc | 200-1000 Vdc | 260-530 Vac | 700 x 501 x 1730 mm | Ethernet / 4G / WiFi / Bluetooth | Quote |
8 models in this line · 3 awaiting final parameter confirmation · link any row with #model-<number>
Applications
Related Guides & Articles
Learn more about this product category from our engineering team.
Certifications You Can Verify
Scope: UL 2202 Edition 3, DC fast charging equipment. The "one of only two" position is a company statement; the certificates themselves are independently checkable in UL Product iQ.
Frequently Asked Questions
What is the difference between a split-type DC charging system and an all-in-one charger?
The FEVD split system separates the 240-720 kW power cabinet from the charging terminals: one cabinet feeds 6, 9 or 10 terminals depending on its rating. Split architecture suits gas stations, fleet depots and highway corridors where several vehicles charge at once. The same FEVD platform also ships as an all-in-one cabinet from 30 kW to 160 kW for compact sites.
Which models are available, and what are their ratings?
Cabinet ratings are 240 / 360 / 480 / 640 / 720 kW, built from hot-swappable 30 kW or 40 kW power modules, with 200-1000 Vdc output and up to 200 Adc per connector. Model numbers, outlet counts and dimensions are listed in the Model Matrix above; request the datasheet for full parameter curves.
Is this system certified for the US market?
The line carries UL, CE and ENERGY STAR certifications. FBK POWER is currently one of only two companies in China whose DC high-power chargers (exceeding 480 kW) have obtained UL certification, the other being BYD. Certificate numbers and the UL Product iQ verification route are published on our certifications page.
Does it support NEVI-funded projects in the US?
The FEVD split-system platform is offered in a NEVI-ready configuration for US highway corridor and public charging projects. Tell us your project's state and funding route when you request a quote so we can configure the system accordingly.
What backend protocol and connectivity does it use?
OCPP 1.6J over Ethernet or 4G. Metering accuracy is Class 1, efficiency is ≥95% at 50-100% load, and power factor is ≥0.99 at ≥50% load with THD <5%.
Can you customize the system (OEM/ODM)?
Yes. Custom branding, firmware customization and hardware modifications are available, including terminal counts and dispenser placement. Share your site layout and target ratings when you request a quote.
